Scrap Metal Briquettes Shredder Scrap Metal Processing Plant Scrap Metal Recycling Shredder

Brand Name:	Xrido
Model Number:	1600 and Customizable
MOQ:	1 set
Payment Terms:	Negotiable

Detail Information

Product Description

Detail Information

Certification:

CE ISO TUV

Place Of Origin:

Henan, China

Video Outgoing-inspection:

Provided

Machinery Test Report:

Provided

Core Components:

PLC, Engine, Bearing, Gearbox, Pressure Vessel, Motor, Gear, Pump

Brand Name:

Xrido

Warranty:

1 Year

Material / Metal Processed:

Stainless Steel, Brass / Copper, Alloy, Carbon Steel, Aluminum

Key Selling Points:

Competitive Price

Product Name:

Waste Shredder Machine

Advantage:

Easy Operation High Efficiency

Machine Type:

Support Customization

Output:

Compact

Final Product:

1-10 Cm

MOTOR:

Famouse Brand

Application:

Metal Plastic Wood Bottle Film

After-sales Service Provided:

Video Technical Support

Condition:

New

Marketing Type:

Ordinary Product

Warranty Of Core Components:

1 Year

Applicable Industries:

Machinery Repair Shops, Building Material Shops, Manufacturing Plant

Delivery Time:

2-30 Working Days

Highlight:

Scrap Metal Processing Plant Shredder

Briquettes Shredder

Scrap Metal Recycling Shredder

Product Description

Scrap Metal Briquettes Shredder Scrap Metal Processing Plant Scrap Metal Recycling Shredder

Products Description

The scrap metal briquette shredder before smelting is a special crushing equipment for scrap metal briquette (such as steel shavings briquette, waste can briquette, car shell briquette, etc.), which is used to tear high-density briquette materials into uniform fragments of 3-10cm, and provide raw materials with uniform particle size for subsequent smelting processes (such as blast furnace ironmaking and medium frequency furnace steelmaking). Its core function is to **break the high-density structure of briquette materials and convert compacted metal blocks into loose, easily fusible particles through mechanical force**. It is commonly found in pre-treatment workshops of steel plants, large scrap metal recycling plants and renewable resource industrial parks.

Scrap Metal Briquettes Shredder Scrap Metal Processing Plant Scrap Metal Recycling Shredder 0

Working principle of scrap metal briquetting shredder:
Dual spindle system: two parallel mounted spindles (speed 10-30rpm), with detachable blades arranged in a spiral line on the shaft;
Hydraulic pressing device: located behind the feed port, the briquetting material is pushed to the blade bite area by a hydraulic cylinder to ensure continuous feeding;
Power system: equipped with a high-power motor (usually 100-300kW) and a planetary gearbox to provide high torque output (up to 100,000 Nm).

Scrap Metal Briquettes Shredder Scrap Metal Processing Plant Scrap Metal Recycling Shredder 1

Product parameters:

model	size(mm)	Shredder room(mm)	Blads(mm)	motor(k)	weight(kg)
XD-600	2800×1300×1850	600×480	200	11×2	2200
XD-800	3000×1300×1850	800×480	200	15×2	2500
XD-1000	3300×1900×2200	1000×690	300	22×2	5200
XD-1200	3600×2000×2200	1200×690	300	30×2	6400
XD-1500	4180×2100×2400	1500×850	550	55×2	9000
XD-1800	5800×2400×3300	1800×1206	550	75×2	13600
XD-2000	6400×2700×3500	2000×1490	600	90×2	20100
XD-2500	7500×3200×3800	2500×1800	600	110×2	25000
Notes: 1. The number of blade claws, diameter, and thickness can be customized according to the type of material and the size of the discharge. 2. The output of the equipment will be different depending on the type of material and the size of the discharge. 3. More information please contact us, we can custom the product on your request.

Advantages of scrap metal briquetting shredder:
Material adaptability: specializes in breaking high-density briquetting (density ≥2.5t/m³), such as steel shavings briquetting and aluminum chips briquetting.
Crushing efficiency: processing capacity 5-20 tons/hour (depending on the density of the briquetting), energy consumption ≤15kWh/ton.
Discharge uniformity: particle size deviation ≤±5mm, meeting the particle size requirements of smelting raw materials.
Equipment loss: blade wear is concentrated on the cutting edge, and the replacement cost is low.
Environmental protection features: fully enclosed cavity + soundproof cover, dust emission ≤20mg/m³, noise ≤80dB.

Scrap Metal Briquettes Shredder Scrap Metal Processing Plant Scrap Metal Recycling Shredder 3

Product Application:

Ferromagnetic metals: fragments of steel parts such as automobile shells, chassis, engine cylinders, gearboxes, etc.
Aluminum products: wheels, engine covers, bumper brackets (aluminum alloy), radiators (aluminum-copper composites), etc.;
Copper products: wires and cables, motor windings, radiator pipes, etc.;
Other metals: lead (battery plates), zinc (die castings), etc.
Plastic and rubber: bumpers, interior parts, sealing strips, tire fragments, etc.;
Glass and ceramics: window glass, dashboard glass, etc.;
Fibers and fabrics: seat fabrics, sound insulation cotton, etc.;
Other impurities: oil, sand, dust, etc.

√ Iron cuttings,sheet iron, sheet steel

√ Copper cuttings, sheet copper, Steel cuttings

√ Scrap iron bar, Waste steel wire

√ Waste wire, Waste steel pipe

√ Scrap metal, Scrap iron pipe

√Scrap metal, Scrap steel, Scrap iron, Scrap aluminum, Scrap radiator, Scrap copper, paint drums, diesel drums, thin iron sheets, car shells, metal briquettes, metal plate scraps etc.

Scrap Metal Briquettes Shredder Scrap Metal Processing Plant Scrap Metal Recycling Shredder 4

Scrap Metal Briquettes Shredder Scrap Metal Processing Plant Scrap Metal Recycling Shredder 5

Key equipment of metal crushing and recycling production line:

Scrap Metal Briquettes Shredder Scrap Metal Processing Plant Scrap Metal Recycling Shredder 6

Scrap Metal Briquettes Shredder Scrap Metal Processing Plant Scrap Metal Recycling Shredder 7


Scrap Metal Shredder Sorting Line	Waste Aluminum Crushing Production Line

Water Radiator Crushing Sorting Line	UBC Aluminum Cans Decoating Machine

Other Metal Recycling Machine

Reliable and durable recycling technologies for material separation and recovery,treatment of various types of solid waste and metal scrap. Metal recycling can benefit your Enhance and economic value , Help you improve recycling eliminate landfilling of waste.

With XRIDO’s ready-to-use spare parts library , you gain peace of mind through seamless maintenance and reduced downtime.
