Waste Shredder Machine
Created with Pixso.

Xrido Double Shaft Metal Waste Shredder for Recycling 1-10cm Output

Xrido Double Shaft Metal Waste Shredder for Recycling 1-10cm Output

Brand Name: Xrido
Model Number: Customizable
MOQ: 1 set
Payment Terms: Negotiable
Detail Information
Certification:
CE ISO TUV
Place Of Origin:
Henan, China
Video Outgoing-inspection:
Provided
Machinery Test Report:
Provided
Core Components:
PLC, Engine, Bearing
Brand Name:
Xrido
Warranty:
1 Year
Material / Metal Processed:
Stainless Steel, Brass / Copper, Alloy, Carbon Steel, Aluminum
Key Selling Points:
Automatic
Name:
Waste Palstic Crushing
Keyword:
Double Shaft Scrap Metal Recycling
Final Product:
1-10 Cm
Advantage:
High Efficiency Low Energy Consumption
Type:
Environment-friendly
After-sales Service Provided:
Service Machinery Overseas
Delivery Time:
2-30 Working Days
Highlight:

double shaft metal shredder

,

waste shredder for recycling

,

1-10cm output shredder

Product Description
Garbage Pre Crusher Machine Solid Waste Recycling Crushing Machine
Double Shaft Shredder for Metal Crushing
Garbage pre-crusher is an important equipment in the solid waste disposal production line. It is typically used as coarse crushing equipment to initially crush large and irregularly shaped garbage into smaller blocks or flakes, providing suitable feed for subsequent sorting, fine crushing and other processes.
Product Specifications
Attribute Value
Place of Origin Henan, China
Brand Name Xrido
Warranty 1 Year
Core Components PLC, Engine, Bearing
Material Processed Stainless Steel, Brass/Copper, Alloy, Carbon Steel, Aluminum
Final Product Size 1-10 cm
Type Environment-friendly
Key Advantages High Efficiency, Low Energy Consumption
Xrido Double Shaft Metal Waste Shredder for Recycling 1-10cm Output 0
Working Principle
The double-shaft shredder crushes garbage by shearing and tearing with blades on two relatively rotating knife shafts. The blades are staggered and driven by a motor to generate shear force while simultaneously squeezing and tearing the garbage into smaller particles.
Product Models and Parameters
Model Size (mm) Shredder Room (mm) Blades (mm) Motor (kW) Weight (kg)
XD-600 2800×1300×1850 600×480 200 11×2 2200
XD-800 3000×1300×1850 800×480 200 15×2 2500
XD-1000 3300×1900×2200 1000×690 300 22×2 5200
XD-1200 3600×2000×2200 1200×690 300 30×2 6400
XD-1500 4180×2100×2400 1500×850 550 55×2 9000
Note: Blade specifications and output may vary based on material type and discharge size. Custom configurations available upon request.
Key Features
  • Strong processing capacity: Large feed inlet accommodates mixed and complex garbage components with varying hardness and toughness
  • Low speed, high torque: Hydraulic or high-power motor drive reduces wear while effectively crushing hard materials
  • Foreign body protection: Automatic ejection system for unprocessable materials prevents equipment damage
  • Process optimization: Uniform particle size output improves efficiency of subsequent sorting and processing stages
Product Images
Xrido Double Shaft Metal Waste Shredder for Recycling 1-10cm Output 1 Xrido Double Shaft Metal Waste Shredder for Recycling 1-10cm Output 2 Xrido Double Shaft Metal Waste Shredder for Recycling 1-10cm Output 3 Xrido Double Shaft Metal Waste Shredder for Recycling 1-10cm Output 4
Applicable Materials
Household Waste
Large items (sofas, mattresses, refrigerator shells), kitchen waste (bone sticks, coconut shells), packaging materials (cartons, plastic bottles)
Industrial Solid Waste
Plastic (pallets, barrels), rubber (tires), metal (cans, iron sheets)
Construction Waste
Concrete blocks, bricks, waste wood for biomass fuel
Specialty Waste
Medical waste (hard packaging), lithium batteries (with explosion-proof design), agricultural waste (straw, branches)
Complete Waste Processing Solution
Our solid waste disposal system integrates pre-crushers, fine crushers, sorters and RDF equipment to achieve reduction, harmlessness and resource utilization through "crushing - sorting - resource utilization" process.
Xrido Double Shaft Metal Waste Shredder for Recycling 1-10cm Output 5 Xrido Double Shaft Metal Waste Shredder for Recycling 1-10cm Output 6 Xrido Double Shaft Metal Waste Shredder for Recycling 1-10cm Output 7 Xrido Double Shaft Metal Waste Shredder for Recycling 1-10cm Output 8
System Advantages
  • 80%+ volume reduction through multi-stage crushing and sorting
  • 85%+ recovery rate for recyclables like metals and plastics
  • 30-40% RDF fuel conversion rate
  • Reduced landfill requirements and lower emissions compared to coal
  • Integrated dust removal and deodorization systems
Final Product Examples
Xrido Double Shaft Metal Waste Shredder for Recycling 1-10cm Output 9 Xrido Double Shaft Metal Waste Shredder for Recycling 1-10cm Output 10
Customer Installations
Xrido Double Shaft Metal Waste Shredder for Recycling 1-10cm Output 11 Xrido Double Shaft Metal Waste Shredder for Recycling 1-10cm Output 12 Xrido Double Shaft Metal Waste Shredder for Recycling 1-10cm Output 13 Xrido Double Shaft Metal Waste Shredder for Recycling 1-10cm Output 14
