Xrido Glass Plate Crusher Waste Shredder Machine 1-10cm Output

All Category

Waste Baler Machine

Mr. Leo

info@xrido.com

86 17513178882

86 17513178882

Contact Now

All Category

Xrido Glass Plate Crusher Waste Shredder Machine 1-10cm Output

Brand Name:	Xrido
Model Number:	Customizable
MOQ:	1 set
Payment Terms:	Negotiable

Detail Information

Product Description

Detail Information

Certification:

CE ISO TUV

Place Of Origin:

Henan, China

Video Outgoing-inspection:

Provided

Machinery Test Report:

Provided

Core Components:

PLC, Engine, Bearing

Brand Name:

Xrido

Warranty:

1 Year

Material / Metal Processed:

Stainless Steel, Brass / Copper, Alloy, Carbon Steel, Aluminum

Key Selling Points:

Automatic

Name:

Waste Palstic Crushing

Keyword:

Double Shaft Scrap Metal Recycling

Final Product:

1-10 Cm

Advantage:

High Efficiency Low Energy Consumption

Type:

Environment-friendly

Material Processed:

PE Film PP Woven Bags

After-sales Service Provided:

Service Machinery Overseas

Delivery Time:

2-30 Working Days

Highlight:

glass plate shredder machine

waste shredder with 1-10cm output

Xrido glass crusher machine

Product Description

Glass Plate Crusher Waste Shredder Machine

Product Overview

The Glass Plate Crusher is a mechanical equipment specially designed for crushing hard glass materials such as flat glass and industrial glass. It efficiently crushes large glass plates into controllable size particles through mechanical force (impact, extrusion, shearing).

Key Specifications

Attribute	Value
Place of Origin	Henan, China
Brand Name	Xrido
Warranty	1 Year
Core Components	PLC, Engine, Bearing
Material Processed	Stainless Steel, Brass/Copper, Alloy, Carbon Steel, Aluminum
Final Product Size	1-10 cm
Key Advantages	High Efficiency, Low Energy Consumption

Working Principle

Compound crusher achieves fine crushing through impact force
Double-tooth roller crusher uses rotating tooth rollers to squeeze and shear glass
Shredder cuts materials through interaction of moving and fixed knives

Applicable Scenarios

Recycling of architectural, automotive, and photovoltaic panel glass
Crushing industrial glass waste (beer bottles, glass cans)
Glass sand preparation (crushing waste glass into sand-like particles)

Technical Specifications

Model	Size (mm)	Shredder Room (mm)	Blades (mm)	Motor (kW)	Weight (kg)
XD-600	2800×1300×1850	600×480	200	11×2	2200
XD-800	3000×1300×1850	800×480	200	15×2	2500
XD-1000	3300×1900×2200	1000×690	300	22×2	5200
XD-1200	3600×2000×2200	1200×690	300	30×2	6400
XD-1500	4180×2100×2400	1500×850	550	55×2	9000

Note: Blade specifications and output may vary based on material type and discharge size. Custom configurations available upon request.

Technical Advantages

High-Efficiency Crushing Capacity

Double-axis staggered shearing design with high-strength alloy cutters handles various materials with 30% higher efficiency than single-axis equipment, producing uniform particle size (10-100mm adjustable).

Strong Adaptability

Customizable with different cutters (hook knives, square knives, round knives) for materials of varying hardness, suitable for electronic waste, large solid waste, and waste tires.

Low Energy Consumption

Hydraulic/motor direct drive system with intelligent overload protection reduces energy consumption by 15-20% compared to traditional crushers, with less than 1% failure rate.

Environmental Benefits

Reduces material volume by 50-80%, lowering transportation costs while providing ideal raw materials for sorting, smelting, and recycling processes.

Main Applications

Hollow containers: Plastic beverage cans, barrels, packing boxes
Waste appliances: TVs, refrigerators, computers, circuit boards
Pipes: Large pipes, PE/PVC tubes
Waste templates: Wooden/plastic pallets, furniture
Scrap tires: Car, truck, and engineering tires
Scrap metal: Car shells, aluminum alloys, engine casings
Various waste materials: Food, medical, garden waste

Product Images

Final Product Examples

Customer Installation Examples
