Xrido AT-TS Tire Shredder 2-3t/D Capacity 55kW Motor

The tire shredder is a mechanical device specially designed for processing waste tires. It uses mechanical force to break down whole tires into smaller rubber blocks or strips for subsequent resource utilization. As coarse crushing equipment in the field of resource recycling, it's engineered to handle the high elasticity and toughness of tires, capable of processing whole tires with steel wires (diameter typically <2000mm) without requiring pre-removal of the ring wire.

The tire recycling line effectively separates materials such as rubber, steel wire, and nylon fiber. The entire system features PLC control for easy operation and maintenance, with low energy consumption and long service life.

• Direct processing of large-size tires: Can process steel wire tires (including mouth wire) with diameter ≤2000mm, without pre-cutting or removing steel wire. Suitable for various types including bias tires and radial tires.
• High processing capacity: 200-10000kg/h. Dual-axis collaboration disperses single-axis pressure, reducing energy consumption and extending equipment life.
• Low-speed high-torque operation: Speed of only 5-13 rpm with ultra-large torque design ensures low noise (≤75 dB) and minimal dust emission, meeting environmental standards.
• Optimized power transmission: Through cycloidal pinwheel or planetary gear reducer to minimize energy consumption.
• Intelligent control: Integrated PLC system supports automatic start/stop, overload protection, and variable frequency speed regulation (5-60Hz), reducing manual intervention and improving safety.

1. Fully automatic wire drawing machine for removing tire steel wheel
2. Conveyor equipment including belt, screw conveyor, and air pressure transmission system
3. Shredder for tearing tires into 50-150mm strips
4. Steel wire separator for processing rubber and steel wire into 10-20mm particles
5. Magnetic separator for sorting steel wire from rubber mixture
6. Crusher for reducing rubber particles to 1-7mm size
7. Vibrating screen for sorting particles and returning oversized material for secondary crushing
8. Fiber separator for removing foreign matter and fiber
9. Secondary magnetic separator for capturing any remaining small wires
10. Mill for grinding particles into powder (30-100 mesh)
11. Fully automatic bagging system for loading finished products
