Xrido AT-TS Tire Shredder 2-3tpd Capacity 55kW Motor

Tire shredder is a mechanical device specially used for processing waste tires. It uses mechanical force to break down the whole tire into smaller rubber blocks or strips for subsequent resource utilization. Tire shredder relies on the mutual engagement and low-speed rotation (5-13 rpm) of dual-axis or multi-axis cutters to break down tires through the combined action of tearing and shearing.

The tire shredder is equipped with high-hardness alloy blades, hydraulic forced feeding system and intelligent control module to ensure processing efficiency and safety.

Solve the pollution problem of waste tire accumulation. The shredded rubber blocks can be used as recycled raw materials for runway paving, cracking and refining, and promote the development of the circular economy.

The tire recycling line can effectively realize the automatic separation of materials such as rubber, steel wire, nylon fiber, etc. The whole line adopts a PLC control system, which is easy to operate and maintain, with low energy consumption and long service life.

• The whole tire is directly put in, no need to pre-break and pull the steel ring
• From the entire tire to 1-7 mm granules, the entire process of production packaging, no secondary handling intermediate links
• According to the customer's output requirements configuration equipment, 200 kg/h-5000 kg/h, a wide range of options

• Fully automatic wire drawing machine: remove tire steel wheel
• Conveyor equipment: conveyor belt, screw conveyor and air pressure transmission system
• Shredder: tear the tire into film(50 mm-150 mm)
• Steel wire separator: separate the rubber and steel wire and process it into rubber particles(10 mm-20 mm)
• Magnetic separator: sorting steel wire from rubber wire mixture
• Crusher: Smash the rubber particles to a smaller size (1 mm-7 mm)
• Vibrating screen: sorting different sizes of rubber particles, and returning the over-sized particles to the crusher for secondary crushing
• Fiber separator: remove foreign matter and fiber
• Secondary Magnetic Separator: Possible Small Wires to Go
• Mill: The particles are ground to a powder (30 mesh to 100 mesh)
• Fully automatic bagging system: loading finished products into storage bags or bags

It can be used to tear up solid materials such as plastic, rubber, fiber, tire, cables, etc. which are hard to break, such as: nozzle material, rubber head, PET bottle, cardboard, circuit board, wood, plastic barrel, etc. You can select the corresponding model according to the material size and handling capacity.
